Top Type Breaker GB58T

♦Breaker’s length is longer and weight is heavier.
♦Easy control and position,more ideal for breaking jobs.
♦Vertical open-bracket design reduces the malfunction rate of chisel.

Detail

Product Introduction

Application Areas

It is widely used in general construction demolition, quarrying and mining, road construction and maintenance, concrete structure breaking, and large-scale engineering projects requiring high-impact efficiency.

Advantages

▪ Its robust top-mount design ensures stable power transmission, with an open-frame structure that balances weight and durability, avoiding the bulk of fully enclosed housings.

▪ High impact energy and efficient power conversion make it ideal for breaking hard materials like rock and reinforced concrete.

▪ The open structure facilitates heat dissipation, reducing the risk of overheating during prolonged operation and enhancing overall reliability.

▪ Optimized structural layout improves operational stability, reducing vibration and extending the service life of both the breaker and the carrier machine.

▪ Equipped with a reliable pressure relief system and overload protection, ensuring safe operation even under heavy workloads.

▪ Designed for easy maintenance: the open-frame design allows quick access to key components, paired with a centralized lubrication system to reduce downtime and extend service intervals.

Description /Model	ARZ55
Operating Weight	206
Setting Pressure	150
Operating Pressure	90~120
Oil Flow Range	25~50
Impact Rate	600~1,100
Hose Diameter	1/2
Tool Shank Diameter	58/2.3
Applicable Carrier Weight	3.0~4.5
Noise Level	89

Technical Specifications

Description/Model	UNIT	GB40T	GB45T	GB53T	GB58T	GB68T	GB75T	GB85T
Operating Weight	Kg	80	100	196	206	298	375	577
Operating Weight	lbs	176	220	431	453	656	825	1,269
Setting Pressure	bar	140	140	150	150	160	180	180
Setting Pressure	psi	2,030	2,030	2,175	2,175	2,320	2,611	2,611
Operating Pressure	bar	90~120	90~120	90~120	90~120	110-140	120-150	130-160
Operating Pressure	psi	1,280~1,707	1,280~1,707	1,280~1,707	1,280~1,707	1,565~1,991	1,707~2,134	1,849~2,276
Oil Flow Range	l/min	15~25	20~30	25~40	25~50	40~70	50~90	60~100
Oil Flow Range	gal/min	4~7	5~8	7~11	6.5~13	10.5~18.5	13~24	16~26.5
Impact Rate	bpm	700~1,200	450~700	600~1,100	600~1,100	500~900	250-400	200-350
Hose Diameter	inch	1/2	1/2	1/2	1/2	1/2	1/2	3/4
Tool Shank Diameter	mm/inch	40/1.6	53/2.1	53/2.1	58/2.3	68/2.7	75/2.9	85/3.3
Applicable Carrier Weight	ton	0.5~1.5	1.2~3.0	2.5~4.5	3.0~4.5	4~7	6~9	7~14
Applicable Carrier Weight	lbs	1,102~3,306	2,645~6,613	5,511~9,920	5,511~9,920	8,818~15,432	13,227~19,841	15,432~30,864
Noise Level	Lₚₐ(dB)	85	90	89	89	89	88	88
